TP-LINK SG3428 Omada 24-Port Gigabit L2+ Managed Switch with 4 SFP Slots
เพิ่มเมื่อ: 2026-09-23 18:30:57.0
แก้ไขล่าสุด: 2026-09-23 18:31:31.0
เบอร์โทรติดต่อ: 062-5193997 , 02-4582949
อีเมลล์: krieng.nt@gmail.comManaged Switch TP-LINK SG3428 Omada 24-Port Gigabit L2+ Managed Switch with 4 SFP Slots
TP-LINK SG3428 Omada 24-Port Gigabit L2+ Managed Switch with 4 SFP Slots
Managed Switch TP-LINK SG3428 Omada 24-Port Gigabit L2+ Managed Switch with 4 SFP Slots
- 24× Gigabit RJ45 ports and 4× Gigabit SFP slots
- 56 Gbps switching capacity
- Centralized cloud management via the web or the Omada app
- Standalone management via web, CLI, SNMP, and RMON
- Static Routing helps route internal traffic for higher efficiency
- VLAN, ACL, QoS, IGMP Snooping, OAM, and DDM
- ERPS supports rapid protection and recovery in a ring topology
- Fanless design for silent operation
- Durable metal casing and rack-mountable design
HARDWARE FEATURES
Interface :
• 24× 10/100/1000 Mbps RJ45 Ports (Auto-Negotiation/Auto MDI/MDIX)
• 4× 100/1000 Mbps SFP Slots
• 1× RJ45 Console Port
• 1× USB Type-C Console Port
Fan Quantity : Fanless
Physical Security Lock : √
Power Supply : 100-240 V~ 50/60 Hz
Dimensions ( W x D x H ) : 17.3 × 7.1 × 1.7 in (440 × 180 × 44 mm)
Surge Protection : ±6 kV
Mounting : Rack Mountable
Max. Power Consumption : 20.6 W (220 V/50 Hz)
Max. Heat Dissipation : 70.30 BTU/h (220 V/50 Hz)
PERFORMANCE
Packet Buffer Memory : 12 Mbit
Jumbo Frame : 9 KB
Switching Capacity : 56 Gbps
Packet Forwarding Rate : 41.66 Mpps
MAC Address Table : 16K
OTHERS
Certification : CE, FCC, RoHS
Package Content :
• SG3428 Switch
• Power Cord
• Console Cable
• Rackmount Kit
• Rubber Feet
• Quick Installation Guide
System Requirements : Microsoft® Windows® 98SE, NT, 2000, XP, Vista™ or Windows 7/8/10/11, MAC® OS, NetWare®, UNIX® or Linux.
Environment :
• Operating Temperature: -5–50 ℃ (23–122 ℉)
• Storage Temperature: -40–70 ℃ (-40–158 ℉)
• Operating Humidity: 10–90% RH non-condensing
• Storage Humidity: 5–90% RH non-condensing
