EnGenius ECS2552FP Cloud 48-Port 740W POE+( 16 x 2.5Gb, 32 x Gigabit), 4 x 10G SFP+
เพิ่มเมื่อ: 2025-01-14 17:25:00.0
แก้ไขล่าสุด: 2025-04-28 12:23:14.0
เบอร์โทรติดต่อ: 062-5193997 , 02-4582949
อีเมลล์: krieng.nt@gmail.comPoE Switch EnGenius ECS2552FP Cloud 48-Port 740W POE+( 16 x 2.5Gb, 32 x Gigabit), 4 x 10G SFP+ (สินค้ารับประกัน 3 ปี)
EnGenius ECS2552FP
PoE Switch EnGenius ECS2552FP Cloud 48-Port 740W POE+( 16 x 2.5Gb, 32 x Gigabit), 4 x 10G SFP+
EnGenius Cloud Managed Layer 2+ Multi-Gigabit 2.5Gb Switch, ECS2552FP, provides SMBs with an easy-to-use and cost-effective network solution. With its 32-Port Gigabit PoE+ and 16-Port 2.5G PoE+ as well as 4-Port 10G SFP+ uplink with 740W budget, it ensures high-speed data transfer for bandwidth-intensive applications. With zero-touch provisioning and centralized cloud management, it simplifies network management and saves time.
- 16x 2.5G PoE+ Ports to unleash elevated speeds for NAS, workstations, or WiFi 6 APs
- 32x Gigabit PoE+ ports for a wide range of network devices such as IP cameras, VoIP phones, workstations, and more
- 4x Dual-Speed 10G SFP+ (fiber) uplink ports to high-speed NAS and servers for a high-performance network
- 48x 802.3af/at PoE+ ports with 740W power budget
- Zero-touch provisioning, centralized cloud management, and visualized monitoring
- Hybrid cloud switch supports flexible management options such as EnGenius Cloud or standalone
- Robust security that supports Port-based / MAC-based ACL Storm control, DHCP Snooping, DOS Attack Prevention, 802.1X & RADIUS Authentication, and more
- Optimized for quality voice and video traffic with Voice-VLAN feature
- PoE Extended Mode - Extend PoE Ethernet cable deploying range up to 250 meters
- PD Lifeguard - Real-time detecting and auto-reboot PoE power for failed camera
Technical Specifications :
Port Standards
802.3u 100Base-TX Ethernet
802.3ab 1000Base-T Ethernet
802.3bz 2.5G/5GBase-T Ethernet
802.3x Full-Duplex Flow Control
Network Ports
32×10/100/1000 Mbps Ports
16×100/1000/2500 Mbps Ports
4x SFP+ Ports
Switching Capacity
224 Gbps
SDRAM
512 MB
Flash Memory
128 MB
PoE Capable Ports
1-48
Total PoE Budget
740W
Power Source
100 ~ 240VAC, 50-60Hz
L2 Features :
Network Management
EnGenius Cloud
Local Web GUI
MAC Address Table
32K
Jumbo frame size
10K
Multicast Group
Max 256 groups
MLD Snooping
MLD Snooping: v1
QoS-number of Priority Queues Supported/
Queue 8
QoS Trust Mode
Cos/802.1p
DSCP
CoS/802.1p-DSCP
Scheduling Mechanism
Strict / WRR/ Strict + WRR
Bandwidth Control
Port-based bandwidth control (Ingress/Egress)
Port Security
Max. 256 Entries
Access Control List (ACL)
MAC Based ACL
IPv4/IPv6 Based ACL
ACL Binding
Web Graphical User Interface (GUI)
HTTP IPv4 / IPv6
HTTPS IPv4 / IPv6
SNMP
SNMP v1/v2c/v3 Support
RMON
RMON 1,2,3,9
System Time
Time Setting/Daylight saving
L3 Features :
Multiple IP Interface
20 IPv6 address
ARP Table
Max. 192 ARP entries
IPv4 Static Route
Max. 63 entries
IPv6 Static Route
Max. 21 entries
Dimensions & Weight :
ECS2552FP Device
Weight: 5.9Kg
Width: 310mm
Length: 440mm
Height: 44mm
Package Contents
1x ECS Managed Gigabit Switch
1x Product Card
1x Power Cord
1x RJ45 Console Cable
1x Rack Mount Kit
