TENDA TEG3210P Managed Switch 8 port Gigabit PoE+2SFP

 เพิ่มเมื่อ: 25/01/2018
 แก้ไขล่าสุด: 17/10/2019
 เบอร์โทรติดต่อ: 062-5193997 , 02-4582949
 อีเมลล์: krieng.nt@gmail.com

รายละเอียด:
TEG3210P Managed Switch 8 port Gigabit PoE+2SFP (สินค้ารับประกัน 5 ปี)
5,500.00 บาท

TENDA TEG3210P

TEG3210P Managed Switch 8 port Gigabit PoE+2SFP

Copper Ports

- 8 10/100/1000Base-T RJ-45 Auto-MDI/MDI-X ports

SFP/mini-GBIC Slots

- 2 1000Base-SX/LX/BX SFP interfaces (Port-9 and Port-10)
- Compatible with 100Base-FX SFP

Switch Architecture

- Store-and-Forward

Backbound Bandwidth

- 20Gbps / non-blocking

Throughout

- 14.88Mpps

Address Table

- 8K entries, automatic source address learning and aging

Share Data Buffer

- 1392 kilobytes

Flow Control

- IEEE 802.3x Pause Frame for Full-Duplex Back pressure for Half-Duplex

Jumbo Frame

- 9Kbytes

Reset Button

- < 5 seconds: System reboot
- > 5 seconds: Factory Default

Dimension

- 294*178.8*44 mm(L×W×H ), 1U high

Weight

- 1.8kg

LED

- Power,PoE-Max
- Link/Act per Gigabit port
- PoE In-Use for Port-1~ 8

Power Consumption

- Max. 115 Watts
- AC 100-240V, 50/60Hz

PoE Standard

- IEEE 802.3af / at PoE / PSE

PoE Power Supply Type

- End-Span

PoE Power Output

- Per Port 51V DC
- Max. 40 Watts

Power Pin Assignment

- 1/2(+), 3/6(-)

PoE Power Budget

- Max. 115 Watts
AC 100-240V, 50/60Hz

PoE Ability

- Number of PD @ 7 Watts 8
- Number of PD @ 15.4 Watts 8
- Number of PD @ 30.8 Watts 4

Management

- Telnet, Web Browser, SNMPv1, v2c

Port configuration

- Port disable / enable
- Auto-Negotiation 10/100/1000Mbps full and half duplex mode selection
- Flow Control disable / enable
- Bandwidth control on each port
- Power saving mode control

Port Status

- Display each port’s speed duplex mode, link status, Flow control status,

  Auto negotiation status, trunk status

Port Mirroring

- TX / RX / Both
- Many to 1 monitor

VLAN

- 802.1Q Tagged Based VLAN, up to 64 VLAN groups
- Q-in-Q tunneling
- Private VLAN Edge (PVE)
- MAC-Based VLAN
- Protocol-Based VLAN
- Voice VLAN
- Up to 10 VLAN groups, out of 160 VLAN IDs

Link Aggregation

- IEEE 802.3ad LACP / Static Trunk
- Supports 5 groups of 10-Port trunk support

QoS

- Traffic classification based, Strict priority and WRR
- 8-Level priority for switching
- Port Number- 802.1p priority- 802.1Q VLAN tag- DSCP/TOS field in IP Packet

IGMP Snooping

- IGMP (v1/v2) Snooping, up to 200 multicast Groups
- IGMP Querier mode support

Regulation Compliance

- FCC,CE,RoHS
