EnGenius ECW260
ECW260 AX1800 Cloud Managed Wi-Fi 6 2×2 Outdoor Access Point
Product Highlight
EnGenius Cloud Managed Wi-Fi 6 2×2 Outdoor Access Point ECW260 supports dual concurrent 802.11ax with backward compatibility, providing up to1,200 Mbps in the 5 GHz band and 574 Mbps in the 2.4 GHz band. Its IP67-rated weatherproof and dustproof housing withstands harsh environments, and its Mesh Wireless Support simplifies setup and self-heals. The EnGenius Cloud App allows remote management of an unlimited number of APs.
- Dual concurrent 802.11ax & backward-compatible with 11ac/a/b/g/n client devices
- Spports up to 1,200 Mbps in 5-GHz band & 574 Mbps in 2.4-GHz band
- IP67-Rated weatherproof & dustproof housing withstands harsh environments
- 2.5 GigE PoE+ compatible port for easy placement where power outlets are scarce
- Four (4) (2x2) detachable 5 dbi high-gain, 360° SMA-type antennas
- Quick-scan device register & configuration and remote monitoring & troubleshooting
- Cloud manage an unlimited number of APs from anywhere with the EnGenius Cloud App
- Mesh Wireless Support simplifies setup, optimizes signals & self-heals
Technical Specifications
Standards
IEEE 802.11b/g/n/ax on 2.4 GHz
IEEE802.11a/n/ac/ax on 5 GHz
Antenna
2 x 2.4 GHz: 5 dBi (External Omni-Directional)
2 x 5 GHz: 5 dBi (External Omni-Directional)
Physical Interface
1 x 10/100/1000/2500 BASE-T, RJ-45 Ethernet Port
LED Indicators
1 x Power
1 x LAN
1 x 2.4 GHz
1 x 5 GHz
Power Source
Power-over-Ethernet: 802.3af/at
Proprietary 48V – 54V
IEEE 802.11e Compliant Source
Active Ethernet (PoE)
Maximum Power Consumption
15.9W
Surge Protection
1KV
ESD Protection
Contact: 4KV
Air: 8 K
Wireless & Radio Specifications
Operating Frequency
Dual-Radio Concurrent 2.4 GHz & 5 GHz
Operation Modes
AP, Mesh
Frequency Radio
2.4 GHz: 2400 MHz ~ 2482 MHz
5 GHz: 5150 MHz ~ 5250 MHz, 5250 MHz ~ 5350 MHz, 5470 MHz ~ 5725 MHz, 5725 MHz ~ 5850 MHz
Transmit Power
2.4 GHz: 23 dBm
5 GHz: 25 dBm
Maximum power is limited by regulatory domain
Tx Beamforming (TxBF)
Increasing signal reliability and transmitting distance.
Radio Chains/Spatial Stream
2×2:2
SU-MIMO
Two (2) spatial streams SU-MIMO for 2.4 GHz and two (2) spatial streams SU-MIMO for 5 GHz up to 1,774Mbps wireless data rate to a single 11ax wireless client device under both 2.4 G Hz and 5 GHz radio.
MU-MIMO
Two (2) spatial streams Multiple (MU)-MIMO for up to 1200 Mbps wireless data rate to transmit to one (1) two streams MU-MIMO 11ax capable wireless client devices under 5 GHz simultaneously
Two (2) Multiple (MU)-MIMO for up to 574 Mbps wireless data rate to transmit to one (1) two streams MU-MIMO 11ax capable wireless client devices under 2.4 GHz simultaneously.
Supported Data Rates (Mbps):
802.11ax:
– 2.4 GHz: 9 to 574 (MCS0 to MCS11, NSS = 1 to 2)
– 5 GHz: 18 to 1200 (MCS0 to MSC11, NSS = 1 to 2)
802.11b: 1, 2, 5.5, 11
802.11a/g: 6, 9, 12, 18, 36, 48, 54
802.11n: 6.5 to 300 Mbps (MCS0 to MCS15)
802.11ac: 6.5 to 867 Mbps (MCS0 to MCS9, NSS = 1 to 2)
Supported Radio Technologies
802.11ax: Orthogonal Frequency Division Multiple Access (OFDMA)
802.11b: Direct-sequence spread-spectrum (DSSS)
802.11ac/a/g/n: Orthogonal Frequency Division Multiple (OFDM)
Channelization
802.11ax supports high efficiency (HE) —HE 20/40/80 MHz
802.11ac supports very high throughput (VHT) —VHT 20/40/80 MHz
802.11n supports high throughput (HT) —HT 20/40 MHz
802.11n supports very high throughput under the 2.4GHz radio –VHT40 MHz (256-QAM)
802.11n/ac/ax packet aggregation: A-MPDU, A-SPDU
Supported Modulation
802.11ax: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM, 1024-QAM
802.11ac: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM
802.11a/g/n: BPSK, QPSK, 16-QAM, 64-QAM
802.11b: BPSK, QPSK, CCK
Max Concurrent User
512 Per radio
Management Features
Multiple BSSID
8 SSIDs for both 2.4 GHz and 5 GHz radios
VLAN Tagging
supports 802.1q SSID-to-VLAN Tagging
Cross-band VLAN Pass-Through
Management VLAN
Spanning Tree
Supports 802.1d Spanning Tree Protocol
QoS (Quality of Service)
Complaint With IEEE 802.11e Standard WMM
Wireless Security
WPA3-PSK (SAE)
WPA3 Enterprise
WPA2 Enterprise (AES)
WPA2 AES-PSK
OWE
Hide SSID in Beacons
Wireless STA (Client) Connected List
Client Isolation
Environmental & Physical
Temperature Range
Operating: -4º~140ºF/-20ºC~60ºC
Storage: -40Fº~176ºF/-40ºC~80ºC
Humidity (non-condensing)
Operating: 90% or less
Storage: 90% or less
Waterproof & Dustproof
IP67-Rated Enclosure
