HIKVISION DS-3E1510P-EI/M 8 Port Gigabit Smart POE Switch
เพิ่มเมื่อ: 2025-05-01 15:06:19.0
แก้ไขล่าสุด: 2025-05-01 15:06:38.0
เบอร์โทรติดต่อ: 062-5193997 , 02-4582949
อีเมลล์: krieng.nt@gmail.comSWITCH (สวิตซ์) HIKVISION DS-3E1510P-EI/M 8 Port Gigabit Smart POE Switch, 8 Gigabit RJ45 PoE ports, 2 Gigabit RJ45 port, 802.3af/at, PoE power budget 60W
HIKVISION DS-3E1510P-EI/M
SWITCH (สวิตซ์) HIKVISION DS-3E1510P-EI/M 8 Port Gigabit Smart POE Switch, 8 Gigabit RJ45 PoE ports, 2 Gigabit RJ45 port, 802.3af/at, PoE power budget 60W
- 8 × Gigabit PoE port,2 × Gigabit RJ45 port
- Total PoE Power Budget 60W
- Support 802.1Q VLAN
- Support PoE watchdog to detect and restart the cameras that do not respond
- Support STP/RSTP Loop prevention
- Support cable detection to locate failure
- Up to 300 m Long Range PoE Transmission
- 6KV Surge Protection
Ports : 8 × Gigabit PoE port,2 × Gigabit RJ45 port
MAC Address Table : 4 K
Switching Capacity : 20 Gbps
Packet Forwarding Rate : 14.88 Mpps
Internal Cache : 1.5 Mbits
PoE Standard : IEEE 802.3af,IEEE 802.3at
PoE Power Pin : End-span: 1/2(-), 3/6(+)
PoE Port : PoE: Ports 1 to 8
Max. Port Power : 30 W
PoE Power Budget : 60 W
Shell : Metal material
Net Weight : 0.54 kg (1.19 lb)
Gross Weight : 1.08 kg (2.38 lb)
Dimensions (W × H × D) : 217.6 mm × 27.6 mm × 108.5 mm (8.57'' × 1.09'' × 4.27'')
Operating Temperature : 0 °C to 40 °C (32 °F to 104 °F)
Storage Temperature : -40 °C to 85 °C (-40 °F to 185 °F)
Operating Humidity : 5% to 95% (no condensation)
Relative Humidity : 5% to 95% (no condensation)
Power Supply : 54VDC, 1.2A
Installation Mode : Desk-Mounted,Wall-Mounted
Max. Power Consumption : 65 W
Power Consumption in Idle : 2.5 W
Surge Protection : 6 KV
Long Range :
Ports 1 to 8: up to 300 m.
Long range performance may vary depend on camera model or cable condition.
Port Isolation :
Ports 1 to 8: port isolation mode to improve network security
Ports in an isolation group cannot communicate with each other, but they can communicate with ports outside the isolation group.
PoE Watchdog :
Ports 1 to 8: auto detect and restart the cameras that do not respond.
Link Aggregation :
Link aggregation is used to aggregate multiple physical ports to form a logical port for load balancing, bandwidth expansion, and port protection.
Support static link aggregation.
Support 3 aggregation groups.
Loop Prevention :
Loop prevention is used to prevent the switching network from forming loops, which will seriously affect network communication. Disabled by default.
Support 802.1D STP.
Suppport 802.1w RSTP.
VLAN :
VLAN is used for network scale planning and network health improvement.
Support 802.1Q.
Configurable VLAN ID from 1-4094.
Support Trunk, Access port mode.
Support Max. 32 VLAN.
